KIWI PRIMER 20K FPGA BOARD

Overview

KIWI Primer 20K  is a development board designed based on Gowin ARORA GW2A-LV18PG256 FPGA chip . The board is equipped with Dual USB interface and HDMI interface. There is also an onboard Gowin U2X USG-JTAG debugger, which make it convenient for users to using.

Features

• Main FPGA Chip : GW2A-LV18PG256 with ARM Cortex-M1 softcore
• Embedded 20736 FPGA logic module unit (LUTs)

• Onboard Gowin GWU2X USB-JTAG debugger

• Onboard HDMI connector, Dual USB connector and microSD socket
• Onboard 512 MB DDR3 SDRAM & 128 Mbit NOR Flash (External)
•  Onboard Power Management IC provides high-efficency output voltage

Target Applications

• Education Development Board
• Industrial Controller
• FPGA IP Verification
