SOM RENESAS AI RZ/V2L

Mechanical Parameters

• Dimensions: 45 mm x 45 mm
• Power supply: 5V/2.5A

• DRP-AI’s excellent power efficiency eliminates the need of heat sinks or cooling fans
• Built-in GreenPAK™ Programmable Mixed-signal Matrix with In-System Programmability
• Built-in OPTIGA™ TPM – Trusted Platform Module

Processor

• Renesas RZ/V2L processor
• Dual 1.2 GHz ARM Cortex-A55
• 200MHz ARM Cortex-M33
• AI Accelerator DRP-AI
• 3D graphics functions (Arm Mali-G31)
• Video codec (H.264/H.265)

Memory

• 2 GB DDR4
• 16 GB eMMC Flash
• 512 Mbit QSPI Flash

Peripherals and Signals Routed to Pins

• 2 x RGMII
• 4 x I2C
• 3 x SPI
• 2 x USB 2.0
• 1 x MIPI DSI
• 1 x MIPI CSI
• 1 x Parallel CSI
• 1 x RGB
• 2 x SCI
• 5 x SCIF
• 8 x ADC
• 2 x CAN

OS Support

• Yocto Linux
• Debian
